Intel Celeron J6412处理器, 3*USB 3.0, 6*USB 2.0, 2*LAN, 6*COM, 3*M.2, 2*HDMI, 3.5寸
|
General |
|
|
CPU |
Intel® Elkhart Lake Celeron® J6412 CPU, Quad-core, up to 2.6 GHz, TDP 10W
|
|
Memory |
DDR4-2666/2933/3200, 1*SO-DIMM, up to 32 GB |
|
Storage |
1*SATA 3.0, 1*M.2 |
|
Expansion Interface |
1*M.2 (Key-E, 2230, PCIe+USB 2.0, Support WiFi+Bluetooth)
1*M.2 (Key-B,2242/3042/3052, PCIe/USB 3.0+PCIe/USB 3.0/SATA+USB 2.0, Default USB 3.0, Support 5G ) |
|
BIOS |
AMI UEFI BIOS |
|
System |
Windows 10, Linux |
|
I/O Interface |
|
|
Ethernet |
2*Intel® 2.5Gbps Ethernet Controller, RJ45 |
|
Serial |
3*RS232, 2*RS232/ TTL, 1*RS232/ RS485/ TTL |
|
USB |
3*USB 3.0, 6*USB 2.0 |
|
Audio |
Realtek® HDA Codec, with MIC/Line-out and Amplifier |
|
GPIO |
8*Programmable GPIO |
|
Display |
|
|
Display Interface |
2*HDMI: max resolution up to 1920*1080@60Hz 1*LVDS/eDP: LVDS, max resolution up to 1920*1200@60Hz eDP, max resolution up to 4096*2160@60Hz |
|
Multiple Display |
Triple |
|
Mechanical & Environment |
|
|
Dimension |
146*105mm |
|
Power Input |
DC 12V |
| Temperature |
Operation: 0℃~60℃, Storage: -20℃~75℃ |
|
Relative Humidity |
Operation: 10%~90%, Storage: 5%~95%, non-condensing |
