工业边缘计算平台, SCM核心模块化设计, 灵活满足机器视觉, 运动控制等负载整合需求
|
General |
|
|
Compute Module |
SCM-D (Skylake-S, H110/Q170) Intel® 6th/7th/8th/9th CoreTM i3/i5/i7, Pentium®, Celeron® CPU DDR4-2133/2400/2666, 2*SO-DIMM, up to 32 GB
SCM-C (Tiger Lake) Intel® 11th CoreTM i3/i5/i7 or Celeron® CPU DDR4 Memory, 1*SO-DIMM, up to 16 GB SCM-C (Skylake-U, Kaby Lake-U, Whiskey Lake)
Intel® 6/7/8th CoreTM i3/i5/i7, or Celeron® CPU DDR4 Memory, 1*SO-DIMM, up to 16 GB
SCM-C (Bay Trail) Intel® Celeron® J1900/J1800 CPU DDR3L-1333, 1*SO-DIMM, upto 8 GB |
|
Storage |
1*mSATA/ M.2 (Key-M, 2242/2280, PCIe x4 NVMe/ SATA SSD) 1*SATA 3.0/2.0 |
|
Expansion Interface |
1*M.2 (Key-E, 2230/2242/2280, WIFI+BT) 2*Mini-PCIe (1*mSATA, 1*Wifi/3G/4G) 1*PCIe x16 Golden Finger SCM-D: 2*PCIe x1 + 1*PCIe x4 + 1*PCIe x16 + 1*USB SCM-C: 2*PCIe x1 + 1*PCIe x4 + 1*USB |
|
BIOS |
AMI UEFI BIOS
|
|
System |
Windows 10, Linux SCM-C (Bay Trail): Windows7/8.1/10, Linux |
|
I/O Interface |
|
|
Ethernet |
2* Intel® 1Gbps PCIe Ethernet Controller, RJ45
|
|
Serial |
4*RS232, 2*RS232/RS485 |
|
USB |
4*USB 3.0, 6*USB 2.0 SCM-C (Bay Trail): 1*USB3.0, 9*USB 2.0 |
|
Audio |
Audio with MIC/Line-out and Amplifier |
|
GPIO |
8 programmable GPIO |
|
Display |
|
|
Display Interface |
1*VGA, 1*HDMI, 1*LVDS/eDP |
|
Mechanical & Environment |
|
|
Dimension |
235*155*57mm |
|
Power Input |
DC12V |
| Temperature |
Operation: 0℃~60℃, Storage: -20℃~75℃ |
|
Relative Humidity |
Operation: 10%~90%, Storage: 5%~95%, non-condensing |
