Seavo Technology

Product&Application / By Type / Mini-ITX

Seavo Mini-ITX Motherboard

Mini-ITX (170*170mm) is a compact standard motherboard form factor which is mechanically compatible with ATX motherboards, includes the super Thin Mini-ITX (board thickness equal to or smaller than 17 mm)

Server

C740 series

C62X series

C232 series

Desktop

Q670 series

H610 series: SV1-12S2A

Intel 12/13/14^th Gen Core i3/i5/i7/i9 with H610 Chipset, 1*PCIe x16, 2*M.2
View product Downloads

Alder Lake -PS: SV1-ADLPS56

Intel 12th Gen Core i3/i5/i7 CPU (Alder Lake -PS), 5*LAN, 4*USB 3.0, PCIe x8
View product Downloads

Q470 series

H420E series: SV1-H422A

Intel 10th Gen Core i3/i5/i7/i9 CPU with H420E, 10*COM, 12*USB, 2*LAN, 1*PCIe x16, 2*M.2
View product Downloads

Q370 series

H310C series: SV1-H3C26C

Intel 6/7/8/9th Gen Core i3/i5/i7 CPU with H310C, SVIO Double-layer rear I/O design, up to 18*COM, 18*USB
View product Downloads

H310 series: SV1-H3126C

Intel 8/9th Gen Core i3/i5/i7 CPU with H310, SVIO Double-layer rear I/O design, up to 18*COM, 18*USB
View product Downloads; SV1a-H3124P

Intel 8/9th Gen Core i3/i5/i7 CPU with H310, 4*COM, 8*USB, 2*LAN, 3*M.2, Thin Mini-ITX
View product Downloads; SV1-H312A

Intel 8/9th Gen Core i3/i5/i7 CPU with H310, 10*COM, 12*USB, 2*LAN, 1*PCIe x16
View product Downloads

Q270 series

H270 series

Q170 series

H110 series: SV1-H1126CU

Intel 6/7th Gen Core i3/i5/i7 CPU with H110, 6*USB 3.0, SVIO Double-layer rear I/O design
View product Downloads; SV1-H1126C

Intel 6/7/8/9th Gen Core i3/i5/i7 CPU with H110, SVIO Double-layer rear I/O design, up to 18*COM, 18*USB
View product Downloads; SV1-H112A

Intel 6/7th Gen Core i3/i5/i7 CPU with H110, 10*COM, 10*USB, 2*LAN, 1*PCIe x16
View product Downloads; SV1-H1116

Intel 6/7th Gen Core i3/i5/i7 CPU with H110, 6*COM, 12*USB, 1*LAN, 1*Mini-PCIe
View product Downloads; SV1a-H1116P

Intel 6/7th Gen Core i3/i5/i7 CPU with H110, 6*COM, 9*USB, 1*LAN, 2*Mini-PCIe, Thin Mini-ITX
View product Downloads

B150 series

H81 series: SV1-H8146

Intel 4th Gen Core i3/i5/i7 CPU with H81, 4*LAN, 1*PCIe x16, 6*COM, 10*USB, TPM
View product Downloads; SV1-H8126C

Intel 4th Gen Core i3/i5/i7 CPU with H81, SVIO Double-layer rear I/O design, up to 18*COM, 18*USB
View product Downloads; SV1-H812C

Intel 4th Gen Core i3/i5/i7 CPU with H81, 12*COM, 10*USB, 2*LAN, 1*PCIe x16
View product Downloads; SV1-H8116

Intel 4th Gen Core i3/i5/i7 CPU with H81, 6*COM, 12*USB, 1*LAN, 1*Mini-PCIe
View product Downloads; SV1a-H8112P-B

Intel 4th Gen Core i3/i5/i7 CPU with H81, 8*USB, 1*VGA, 1*HDMI, 1*LVDS, 2*Mini-PCIe, DC 19V
View product Downloads

B85 series

B75 series

H61 series: SV1-H612A-B

Intel 2nd/3rd Gen Core i3/i5/i7 CPU with H61, 10*COM, 8*USB, 2*LAN, 1*PCIe x16
View product Downloads; SV1-H6116

Intel 2nd/3rd Gen Core i3/i5/i7 CPU with H61, 6*COM, 8*USB, 1*LAN, 1*PCIe x16
View product Downloads

Mobile

Meteor Lake-P: Intel McLaren Island Reference Design Board

Intel® Core™ Ultra processors (Series 1) (Meteor Lake -P)
View product Downloads

Raptor Lake -P

Alder Lake -P: SV1a-12P26B

12th Intel Alder Lake-P CPU, 6*USB 3.0, 2*LAN, 6*COM, 3*M.2
View product Downloads

Tiger Lake: SV1a-11514

11th Intel Core/ Celeron CPU, 4*COM, 12*USB, 1*LAN, 2*M.2, Thin Mini-ITX
View product Downloads

Ice-Lake-U

Whiskey Lake: SV-POS422

Intel Celeron 4205U CPU, 2*eDP, 1*LAN, 8-12*USB, 2*COM, 1*mSATA, 1*M.2, 1*RJ11
View product Downloads; SV1a-86614P

Intel Core i7-8665UE CPU, 4*COM, 10*USB, 1*LAN, 1*M.2,Thin Mini-ITX
View product Downloads

Kaby Lake-U

Kaby Lake-U Skylake-U: SV1a-70216EP

Intel Core i3-7020U CPU, 6*COM, 10*USB, 1*LAN, 2*Mini-PCIe, Thin Mini-ITX
View product Downloads; SV1a-38514P-C

Intel Celeron 3855U CPU, 4*COM, 9*USB, 1*LAN, 2*Mini-PCIe, Thin Mini-ITX
View product Downloads; SV1-38526C

Intel Celeron 3855U CPU, SVIO Double-layer rear I/O design, up to 18*COM, 13*USB, DC 12V Power Input
View product Downloads; SV1-38516P

Intel Celeron 3855U CPU, 6*COM, 12*USB, 1*LAN, 1*Mini-PCIe, 1*RJ11, DC 12V Power Input
View product Downloads

Ivy Bridge: SV1-1371A

Intel Celeron 1037U CPU, 10*COM, 8*USB, 1*LAN, 1*PCIe x16, 2*Mini-PCIe
View product Downloads; SV1a-13714P

Intel Celeron 1037U CPU, 4*COM, 7*USB, 1*LAN, 2*Mini-PCIe, Thin Mini-ITX
View product Downloads; SV1-13716P

Intel Celeron 1037U CPU, 6*COM, 8*USB, 1*LAN, 2*Mini-PCIe, ATX or DC 12V Power Input
View product Downloads

Former Mobile

Atom

Alder Lake-N: SV1a-12N16

Intel Alder Lake-N CPU, 11*USB, 6*COM, 1*LAN, 2*M.2, 1*HDMI, 1*eDP/LVDS, 1*eDP
View product Downloads; SV1a-10016

Intel Alder Lake-N CPU, 11*USB, 6*COM, 1*LAN, 2*M.2, 1*HDMI, 2*eDP
View product Downloads

Elkhart Lake: SV1-64126

Intel Elkhart Lake Celeron CPU, 2*GbE LAN, 9*USB, 6*COM, 1*Mini-PCIe, 1*M.2
View product Downloads; SV1a-64112A

Intel Elkhart Lake Celeron CPU, 10*USB, 4*COM, 1*Mini-PCIe, 1*HDMI, 1*eDP, 1*eDP/LVDS
View product Downloads; SV1a-64116

Intel Elkhart Lake Celeron CPU, 11*USB, 6*COM, 1*LAN, 3*M.2, 1*HDMI, 2*eDP
View product Downloads

Jasper Lake: SV1a-51526

Intel Jasper Lake Celeron CPU, 11*USB, 6*COM, 2*LAN, 2*M.2, 1*PCIe x4, 2*HDMI, 2*eDP
View product Downloads

Gemini Lake: SV1a-41226

Intel Gemini Lake Celeron CPU, 9*USB, 6*COM, 2*LAN, 2*M.2, 1*Mini-PCIe, Thin Mini-ITX
View product Downloads

Apollo Lake: SV1a-34526

Intel Celeron J3455 CPU, 6*COM, 9*USB, 2*LAN, 1*Mini-PCIe, 2*M.2, Thin Mini-ITX
View product Downloads; SV1-34526

Intel Celeron J3455 CPU, 6*COM, 4*USB 3.0, 7*USB 2.0, 2*LAN, 1*mSATA, 2*M.2
View product Downloads; SV1a-34516P

Intel Celeron J3455 CPU, 6*COM, 10*USB, 1*LAN, 2*Mini-PCIe, 1*RJ11, Thin Mini-ITX
View product Downloads

Braswell

Denverton

Rangeley

Bay Trail: SV1a-19016LP

Intel Celeron J1900 CPU, 6*COM, 9*USB, 1*LAN, 1*RJ11, supports Dual display of 2*eDP, Thin Mini-ITX
View product Downloads; SV1a-19016EP

Intel Celeron J1900 CPU, 6*COM, 9*USB, 1*LAN, supports Dual display of 2*eDP, Thin Mini-ITX
View product Downloads; SV1a-19014P

Intel Celeron J1900 CPU, 4*COM, 9*USB, 1*LAN, 2*Mini-PCIe, Thin Mini-ITX
View product Downloads; SV1-19016EP

Intel Celeron J1900 CPU, 6*COM, 10*USB, 1*LAN, 1*RJ11, supports Dual display of 2*eDP
View product Downloads; SV1-1900EP

Intel Celeron J1900 CPU, 2*COM, 10*USB, 1*LAN, 1*RJ11, supports Dual display of 2*eDP
View product Downloads; SV1-19026P

Intel Celeron J1900 CPU, 6*COM, 9*USB, 2*LAN, 1*Mini-PCIe
View product Downloads; SV-1900D

Intel Celeron J1900 CPU, 2*COM, 10*USB, 1*LAN, 1*Mini-PCIe
View product Downloads; NVR SV1-190A6

Intel Celeron J1900 CPU, 17*SATA, 1*mSATA, 2*LAN, 1*VGA, 2*HDMI, DC 12V Power Input
View product Downloads

Cedar Trail: SV1-25526P-B

Intel Atom D2550 CPU, 6*COM, 7*USB, 2*LAN, 2*Mini-PCIe, 1*PCI, DC 12V or ATX PSU Power Input
View product Downloads; SV1a-25514P-C

Intel Atom D2550 CPU, 4*COM, 8*USB, 1*LAN, 1*mSATA, Thin Mini-ITX
View product Downloads
